| # | Description | Price | Qty |
|---|---|---|---|
| 1 |
CRANKSHAFT ASSY
6H4-11400-14-00 |
$1,118.79 |
|
| 2 |
.GEAR, DRIVE
6H4-11536-00-00 |
$99.81 |
|
| 3 |
.BEARING
93306-305U8-00 |
$36.81 |
|
| 4 |
.BEARING
93306-305U8-00 |
$36.81 |
|
| 5 |
CIRCLIP, OUTER
93440-62057-00 |
$4.13 |
|
| 6 |
WASHER, PLATE
90201-50306-00 |
$5.16 |
|
| 7 |
PISTON (STD)
6H4-11631-01-95 |
$98.51 |
|
| 7 |
PISTON (0.50MM O/S)
6H4-11636-01-00 |
$98.51 |
|
| 8 |
PISTON RING SET (STD)
6H4-11601-00-00 |
$57.87 |
|
| 8 |
PISTON RING SET (0.50MM O/S)
6H4-11601-20-00 |
Unavailable | |
| 9 |
PIN, PISTON
648-11633-00-00 |
$11.16 |
|
| 10 |
PIN, DOWEL
93602-20M02-00 |
$2.80 |
|
| 11 |
WASHER, PISTON PIN
6H4-11641-00-00 |
$6.20 |
|
| 12 |
CLIP, PISTON PIN
6H4-11634-01-00 |
$2.23 |
|
| 13 |
GASKET, OIL SEAL HOUSING
6H4-15369-A1-00 |
$5.60 |
|
| 14 |
HOUSING, OIL SEAL
6H4-15396-02-5B |
$27.86 |
|
| 15 |
OIL SEAL
93102-25M28-00 |
$9.92 |
|
| 16 |
OIL SEAL
93101-16M36-00 |
$6.48 |
|
| 17 |
.O-RING
93210-57M09-00 |
$6.20 |
|
| 18 |
BOLT, HEXAGON
97313-06020-00 |
Unavailable | |
| 19 |
WASHER, PLATE
92990-06600-00 |
$2.50 |
|
