Yamaha Waverunner 1989 OEM Parts Diagram for Crankshaft Piston

#	Description	Price	Qty
1	Crankshaft Assembly 6K8-11400-00-00	Unavailable
2	. O-Ring 93210-16716-00 In Stock	~~$1.20~~ $1.03	Add
3	. Bearing 93306-306U3-00 Ships in 2 to 3 days	~~$82.99~~ $57.18	Add
4	. Circlip, Outer 93440-62021-00	Unavailable
5	. Bearing 93306-30564-00 In Stock	~~$56.99~~ $45.99	Add
6	Washer, Plate 90201-50306-00 In Stock	~~$5.80~~ $5.16	Add
7	Oil Seal, S-Type 93101-25M38-00	Unavailable
8	Piston (Std) (Std) UR 6K8-11631-00-95 Ships in 2 to 3 days	~~$104.99~~ $71.24	Add
8	Piston 2 O/S 0.50 (0.50Mm O/S) Alt. Part 6K8-11636-00-00 Ships in 2 to 3 days	~~$104.99~~ $71.24	Add
9	Piston Ring Set (2Nd O/S) Alt. Part 6K8-11610-21-00	Unavailable
9	Piston Ring Set (Std) UR 6K8-11610-01-00	Unavailable
10	Pin, Dowel 93602-20M02-00 In Stock	~~$2.80~~ $2.80	Add
11	Pin, Piston 689-11633-00-00 Ships in 2 to 3 days	~~$11.95~~ $9.84	Add
12	Clip, Piston Pin 688-11634-00-00 In Stock	~~$4.45~~ $4.45	Add
13	Washer, Plate 90201-20M27-00	Unavailable
14	Bearing 93306-305U6-00	Unavailable
15	Oil Seal 93101-25M35-00 Ships in 2 to 3 days	~~$18.99~~ $13.10	Add
16	Pin, Dowel 93606-12019-00 In Stock	~~$3.50~~ $2.79	Add
17	Gasket, Upper Casing 6K8-45113-00-00	Unavailable
18	Shaft, Drive 4 6K8-45514-00-00	Unavailable
19	Flange Coupling 6K8-45813-00-9M Ships in 2 to 3 days	~~$92.99~~ $63.74	Add
20	Rubber Shaft Cplng 6K8-4581J-00-00 Ships in 2 to 3 days	~~$106.99~~ $76.24	Add
21	Washer, Plate 90201-20M21-00 In Stock	~~$5.95~~ $5.95	Add

Yamaha WR500F Crankshaft Piston Diagram
